Relipowertech DIN Rail Power Supplies 75W （SDR-75 Series）

AC-DC Industrial DIN rail power supply; ranging from 75~960W, Metal casing; Ultra slim width.

High efficiency 90% and low power dissipation

Can be installed on DIN rail TS-35/7.5 or 15

Protections: Short circuit / Overload / Over voltage / Over temperature

Output Voltage

Output Current

Clear

Spec	SDR-75-12	SDR-75-24	SDR-75-48
Wattage	76	77	77
Input Voltage	88~264VAC, 124~370VDC	88~264VAC, 124~370VDC	88~264VAC, 124~370VDC
Output Current	0~6.3	0~3.2	0~1.6
Output Voltage	12	24	48
Output Voltage Options	Single	Single	Single
DC output adjustment	12~14V	24~28V	48~55V
Dimensions	32x 125.2x 102	32x 125.2x 102	32x 125.2x 102
Working Temperature	-25~+70°C
Safety Standards	UL508, TUV EN60950-1 approved, design refer to GL
EMC Standards	Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A, SEMI F47 approved
